600 MXZ

The 2 cylinder Rotax cylinder reed valve designed motor with the reed valves mounted onto the cylinders offers more power than the 583 rotary valve motor. Twin trail pipes will net 10 HP with 3-4 pounds of torque @ 8200-8300 RPMs. V-Force 3 Reeds will enhance this motor without a doubt. We highly recommend trail porting with Crank Shop pipes. Trail porting has a 6-8 HP gain with 4-5 pounds of torque. For race modifications the Improve Stock Package turns @ 9200 RPM's with 140 HP - 81 lbs. torque and the Prostock Package is 157 HP @ 9400 RPM's 88 lbs. of torque. Both motor packages will run a race fuel such as C12 or C14. Race packages are not for a trail motor. The labor to disassemble, clean, and assemble the motor is NOT included in the package price. Any crank work, repairs, or replacement OEM parts would be an extra charge.

In stock
SKU
600 MXZ
Grouped product items
Product Name   Model Price Qty
Trail Porting (send cylinders, rave valves, & head)
1037000
$467.25
Race Porting (send cylinders & rave valves)
1037100
$624.75
Tunnel Porting Base Trail
1037200
$141.75
Tunnel Porting Base Race
1037300
$278.25
600 MXZ Improve Stock Package
1037500
$2,905.00
600 MXZ Pro Stock Package
1037400
$2,690.00
Flat Head Cut
1031300
$60.00
Machine 2 Cyl. Head for Inserts 1051205
1051205
$175.00
600 Head Inserts (each) (A2-4)
1055350
$123.25
Offset Bore Carbs to 45mm (each)
1044500
$55.75
600 MXZ Trail Pipes into Crank Shop Muffler
1026040
$1,200.00
600 MXZ Silenced Trail Pipes
1026000
$940.00
600 MXZ Improve Stock Pipes w/Steel Silencers
1026020
$1,125.00
600 MXZ Standard Piston & Ring Flat Top (F1-6)
420889173
$160.00
600 MXZ/500 SS .010 OEM Ski Doo (Rotax) Piston 420889171 (F1-7)
420889174-1
$160.00
600 MXZ Ski Doo (Rotax) SPI Piston (WPS# 54-785PS)
54785PS-1
$108.95
600 MXZ SPI Piston .010 over (WPS# 54785P1)
54785P1-3
$108.95
600 MXZ SPI Piston .020 over 76.50mm (WPS#54-785P2)
54785P2-3
$108.95
600 MXZ Piston Cir Clip OEM 20mm Sold As Each (420845106) (FC4-4)
420845106-3
$4.25
V-Force 3 Reeds (V3120-794A-2)
V312794A2
$255.00
V-Force Reed Gasket Small Reed Cage 440, 500, 600 2 Cylinder & 600, 700, 780, 800,1006, 1019, 1025 & 1100 3 Cylinder (G3120)
G3120-3
$4.95
Base Gasket Reed 440 2000-07/600 MXZ 1999-2003 2 Cyl.3mm .012 3 Hole NLA (420931580) (FC3-1)
420931580-1
$13.00
Out of stock
Base Gasket Reed 440 2000-07/600 MXZ 1999-2003 2 Cylinder 4mm .015 4 Hole (420931581) (FC3-1)
B0368015F-1
$15.75
Base Gasket Reed 440 2000-07/600 MXZ 1999-2003 2 Cylinder 5mm .020 5 Hole (420931583) Supersedes to part# 420431420.(FC3-1)
420431420-1
$22.50
Base Gasket Reed 440 2000-07/600 MXZ 1999-2003 2 Cylinder 6mm .024 6 Hole (420431421) (FC3-1)
420431421
$19.50
Base Gasket Reed 440 2000-07/600 MXZ 1999-2003 2 Cylinder 8mm .030 8 Hole (420931584) Supersedes to part# 420431423.(FC3-1)
420431423-1
$22.50
Cometic Base Gasket 1999-2003 600 & 1999 700 MXZ 2 Cylinder .039 (B0368039F) (FC3-1)
B0368039F-1
$15.75
Cometic Base Gasket 1999-2003 600 & 1999 700 MXZ 2 Cylinder .060 (B0368060F) (FC3-1).
B0368060F
$15.75
Cometic Aluminum Shim 1999-2003 600 MXZ 2 Cylinder .040 (B0368040A) (FC3-1)
B0368040A
$23.50
Cometic Aluminum Shim 1999-2003 600 MXZ 2 Cylinder .080 (B0368080A) (FC3-1)
B0368080A
$23.50
Inner Oring OEM 583, 600, 600HO, 2 Cylinder 293300026 (FC2-1)
293300026-2
$19.50
Inner Oring Aftermarket 82mm x 2mm Viton 583, 600, 600HO, 700 2 Cylinder & 992, 1006, 1019 3 Cylinder (FC2-1)
82 x 2-1
$5.50
Outer Orings OEM Reed Cylinder 500, 600, 600HO, 600RS, 700, 800, 800HO 2 Cylinder (420931590) (FC2-2)
420931590-2
$11.00
Head Cover Oring 500, 500SS, 600, 600HO, 700 2 Cylinder Reed (420950320) was part#290950320 (FC2-3)
420950320-2
$13.50
Spark Plug Orings OEM RV 500 (494), Reed 500SS, 600, 600HO, 700, and 3 Cylinder 600, 700, 780, and 809. (420430782) (FC2-2)
420430782-3
$5.25
Exhaust Gasket 600 1999-2003 & 500SS 2004-2009 2 Cyl. (420931610) (FC2-3)
420931610-1
$11.50
Rave Gasket 500 MXZ Reed 2000-03, 500SS 2004-09, 600 MXZ 1999-2003, 700 MXZ 2000-03, All 3 Cyls. 600/700/800/1006/1019/1025/1100
420250239-4
$8.50
Thermostat Gasket (420850338) was part# 420850336 (FC2-4)
420850338-6
$11.00
Water Pump Gasket 2 Cylinder Reed 500, 500SS, 600, 600HO, 600RS, 700, 800 & 800HO Supersedes to 420931811 (420931810) (FC2-4)
420931810-4
$13.00
